A2212/13T 1800KV 4max Brushless Motor

Part Number

A2212-1800kv

RPM/Volt with no Load

1800kv

Diameter

28mm

Length

27mm

Weight

53g inc wires and connectors

Shaft Diameter

3.175mm (3.2mm)

Shaft Length

11mm

Bulkhead to Prop Length

40.5mm

Max current (efficiency)

4-10A (>75%)

Voltage Input Range

6V ~ 12.6 (2-3 LiPo Battery)

Connectors

3x 3.5mm Gold plated male bullet connectors

Thrust/Speed

490g/1.08lbs Using the supplied 7×3.5 prop at 11.1V (11.5A). Est Speed 52MPH

Suitable Battery

3S 800mAh / 3S 1000mAh / 3S 1300mAh
